Operating System
|
Windows® Embedded Handheld 6.5 Professional
Windows® Embedded Handheld 6.5 Classic
|
|
Mobile Computing Platform
|
TI AM3715 1GHz
|
|
Display
|
3.5" TFT LCD VGA (480 x 640)
600 nits QuadraClear® sunlight readable display
Pressure sensitive touchscreen
|
|
Storage & Memory
|
512MB MDDR
256MB NAND flash and 8GB iNAND
|
|
Keypad
|
Phone numeric keypad
|
|
Expansion Slots
|
FlexiConn™
Micro SDHC (up to 32GB)
|
|
IO Interface
|
Serial port (9-pin; D-sub) x 1
USB OTG (client 2.0 and host 2.0; 5-pin; type Mini AB) x 1
Microphone x 1
Speaker x 1
DC in Jack x 1
Docking connector (4-pin) x 1
|
|
Communication Interface
|
Optional 3.5G WWAN (HSPA+/UMTS/EDGE/GPRS/GSM) for data and voice communication
802.11 b/g/n
Bluetooth (v2.1+EDR class 2)
GPS (with internal antenna)
|
|
GPS Sensor Specifications
|
Chipset: SiRFstarIV™
Receiver Type: L1 (C / A)
Channels: 48 channels all-in-view tracking
Update Rate: 1 Hz
Horizontal Accuracy:
i) Autonomous: 8.2 ft
ii) DGPSi: 6.56 ft
Cold Start Time: 35 sec average
Hot Start Time: 1 sec average
Reacquisition: 0.1 sec average
|
|
Software
|
Microsoft Internet Explorer Mobile®
Windows® Office Mobile 2010
Windows® Office Outlook Mobile
Windows® Media Player Mobile
Microsoft ActiveSync 4.5 for data sync
|
|
Field Service Features
|
GPS: SiRFstarIV™
5M pixels auto focus camera with LED light
E-compass
Altimeter
Optional 13.56MHz RFID and contactless smart card reader (ISO 15693 and 14443 A/B compliant)
|
|
Alphanumeric Data Entry
|
Soft input panel (SIP) on screen keyboard
Transcriber handwriting recognition
Phone numeric keypad
Nuance XT9® Soft input panel (SIP)
|
|
Security Features
|
WiFi for WPA / WPA2 operation
Authentication: OPEN, SHARED-KEY, PEAP
Encryption: WEP, AES, TKIP
|
|
Power
|
AC charger (24W; 12V/2A, 100-240VAC; 50 / 60 Hz)
Li-lon smart battery (5600mAh) (up to 12 hours of battery life)ii
Charging time: Sleep mode, approx. 3.5 Hrs.
LifeSupport™ battery swappable technologyiii
|
|
Dimensions & Weight
|
89 x 30 x 178 mm,
530 g without 3G moduleiv
|
|
Inbox Accessories
|
AC charger
USB cable
Hand strap
Quick start guide
Battery
Stylus
Stylus tether
|
|
Rugged Features
|
MIL-STD-810G and IP68 certified
Vibration resistant
Drop resistant (26 drops from 6ft)
Tumbling resistant (1,000 cycles; 1.6 ft)
Optional EU explosive atmosphere ATEX certifiedv
|
|
Environmental Specifications
|
Temperature:
- Operating: -30°C to 60°C
- Storage: -40°C to 70°C
Humidity:
- 95% RH , non-condensing
|
