PM500 Specification
-
Dimensions
179mm x 77.5mm x 64mm (TBD)
7.05in x 3.05in x 2.52in
-
Weight
450g (15.87oz)
-
Power
7.4V 3,000mAh
-
Display
5.0", 720 x 1280 pixels, HD
LED backlight, wide-viewing angle, daylight readable (500+ Nits) Multi-touch capacitive, Stylus
-
OS
Android 7.1 Nougat
-
Processor
Qualcomm MSM8909 1.1GHz
-
Memory and Storage
1GB/8GB (RAM/ROM)
-
Communication
Radio Frequency Band
EU/KR LTE: B1/B3/B5/B7/B8/B20/B38/B40/B41
WCDMA: B1/B5/B8,GMS 850/900/1800/1900MHz
North America LTE: B2/B4/B5/B7/B12/B13/B25/B26
WCDMA: B1/B2/B4/B5/B8
GSM: 850/1900MHz
Japan LTE: B1/B3/B8/B18/B19/B26/B41
WCDMA: B1/B6/B8/B19
Wireless LAN
IEEE 802.11a/b/g/n, IEEE 802.11d/h/i/k/r/v
Bluetooth
4.2 BLE, Class I
Wired LAN
Dial-Up Modem with Docking Station
Ethernet: Cradle: 10/100 Ethernet MAC with Full- Duplex, RJ45 with LED status (data and link) (optional)
-
Data capture
Scanning
1D/2D barcode scanner (optional)
NFC
ISO Standards: ISO14443A/B, ISO15693, ISO18092 (NFC IP-1), ISO21481 (NFC IP-2) Frequency of 13.56Mhz HF
Supported Tags: ISO14443A/B, FeliCa, ISO15693 MiFare® (Classic 1k/4k, Plus, UltraLight, DesFire)
Camera
Rear 8MP (optional)
Front 2MP
RFID
900MHz UHF (optional)
-
Payment
MSR
Track 1/2/3, bi-directional
Contact
EMV Contact L1/L2
Contactless
EMV Contactless L1 / EMV Kernels (VISA, Master, Union-Pay, AMEX, JCB, D-PAS)
Security
PCI PTS 5.x PED
-
Printer
Size
2in (Width: 58mm, Diameter: 40mm)
Speed
Max. 85mm/second
|
