Optical & Performance
- SensorLinear Image Sensor
- Aiming Element70,000 Lux (Sunlight)
- Printing Contrast Scale30%
- Depth of FieldLabel / DOF │ near │ far
Code 39, 4mil │50mm │70mm
Code 39, 5mil │45mm │ 95mm
Code 39, 10mil │40mm │190mm
Code 39, 15mil │ 55mm │265mm
UPC/EAN, 13mil │ 50mm │ 225mm
Communication
- Host Interface supportedBluetooth® 4.1HID (HID Keyboard Device)
USB HID (HID Keyboard Device)
USB VCP (Virtual COM Device)
Batch Mode (Mass Storage Device)
Mechanical
- DimensionW29 x L46.5 x H27 mm
- Weight20.5g (including Velcro strap)
Symbologies
- 1D BarcodesUPC-A/UPC-E, EAN-8/EAN-13, Industrial 2 of 5, Codabar, Matrix 2 of 5, Code 11, Code 93, Code 32, Code 128, Standard Code 39, Full ASCII Code 39, Interleaved 2 of 5, China Postal Code, MSI Plessy Code, UK Plessy Code, EAN/UCC 128, Telepen Code, IATA Code, GS1 Databar
Environmental
- ESD ProtectionFunctional after 4KV contact, 8KV Air discharge
- Mechanical Shock1.5M onto concrete (scanner only)
- Operating Temperature0°C to 50°C
- Storage Temperature-20°C to 60°C
- Relative Humidity95% non-condensing
- IP RatingIP42
|
