Operation System
- OSWindows 10 IOT Enterprise
- CPU2.4G, Intel® Atom™ X5-Z8550 Quad Core Processor
- Memory8GB RAM
128GB Flash
- OthersTPM (Trusted Platform Module) 2.0 support
Display
- Screen Size10.1" (1920 x 1200) WUXGA color screen with Backlight 470 nits
- Touchpanel10-point multi-touch and capacitive stylus, support glove mode and wet-touch mode
Camera
- Camera2MP front camera
8MP rear camera, AF with LED flash
Symbologies
- 2D Barcodes(Honeywell N3680)
Linear: Codabar, Code 11, Code 128, Code 2 of 5, Code 39, Code 93 and 93i, EAN/JAN-13, EAN/JAN 8, IATA Code 2 of 5, Interleaved 2 of 5, Matrix 2 of 5, MSI, GS1 DataBar, UPC-A, UPC-E, UPC-A/EAN-13 with Extended Coupon Code, Coupon GS1 Code 32 (PARAF), EAN-UCC Emulation 2D Stacked: Codablock A, Codablock F, PDF417, MicroPDF417 2D Matrix: Aztec Code, Data Matrix, MaxiCode, QR Code, Chinese Sensible (Han Xin) Code Postal: Australian Post, British Post, Canadian Post, China Post, Japanese Post, Korea Post, Netherlands Post, Planet Code, Postnet
RFID
- HF RFIDOptional HF/NFC
Frequency 13.56Mhz Support: ISO14443A/B, ISO15693 standard
Communication
- Bluetooth®Bluetooth® 4.1
- WLAN802.11 a/b/g/n/ac (2X2 MIMO)
- WWAN4G LTE Full Band
- SensorsLight, G-Sensor, Gyroscope and eCompass
I/O Interfaces
- USBFull size USB 3.0 x1
Full size USB 2.0 x1"
- POGO PINPOGO pin
- SIM SlotSIM Card Reader
- Expansion SlotDocking connector
RJ45 10/100 Ethernet Port Replaceable DC jack Micro HDMI Micro SDXC Card Reader
- Audio3.5mm Audio jack
Enclosure
- Dimensions ( W x D x H )283.4 mmx 192mm x 21.9mm
- Weight1200g
Durability
- Drop Specification1.5m
- SealingIP65
- Vibration and Shock testMIL-STD 810G, shock & vibration
Environmental
- Operating temperature-10~50°C
Power Source
- Main battery3.7V, 10800 mAh
40Wh Hot swappable
What comes in the box
- The standard package contentsTB162
Power Adaptor (AC/DC adapter and AC power cord(US) Battery pack
Accessories
- AC Adapter 65W (19V / 3.42A)
- Hand strap with stylus holder
- Capacitive stylus pen
- Vehicle Dock
- Office Dock
- Battery Charger
|
