| Operating System |
Windows Server 2019 |
| |
______________________________ |
| Mobile Computing Platform |
Intel® Xeon® Processor E3-1505M v6 3.0GHz,
Max. 4.0GHz
- 8MB Intel® Smart Cache |
| |
______________________________ |
| VGA Controller |
Intel® HD Graphics P630
Optional: NVIDIA® GeForce® GTX1050 4GB discrete graphics controller
Optional: NVIDIA® Quadro® P2000 4GB discrete graphics controller |
| |
______________________________ |
| Display |
15.6" TFT LCD FHD (1920 x 1080)
Protection film
1,000 nits QuadraClear® sunlight readable display |
| |
______________________________ |
| Storage & Memory |
32GB DDR4 / 32GB DDR4 ECC
Optional: 64GB DDR4 / 64GB DDR4 ECC
500GB SATA HDD / 512GB SATA SSD
Optional: 1TB SATA HDD / 1TB SATA SSD
Disk management: RAID 0 / RAID 1 i |
| |
______________________________ |
| Keyboard |
LED backlit membrane keyboard with integrated numeric keypad
Optional: LED backlit rubber keyboard |
| |
______________________________ |
| Pointing Device |
Touchpad
- Glide touchpad with scroll bar |
| |
______________________________ |
Expansion Slots
(Will have same disclaimer number and Dimensions
(disclaimer number vary from model to model) |
Smart card reader x 1
ExpressCard/54 x 1
PCMCIA Type II x 1
Without SD Card Reader starting March 5th, 2021 |
| |
______________________________ |
| Multimedia Bay |
2nd storage: HDD 500GB
Optional 2nd storage: 1TB HDD / 512GB SSD / 1TB SSD
Optional 2nd battery ii: 10.8V, 9240mAh, 99.8Wh |
| |
______________________________ |
| X Bay |
Optional: SATA HDD / SSD 3TB maximum expandable to 5TB
Disk management: RAID 0, RAID 1, RAID 5 |
| |
______________________________ |
| I/O Interface |
Audio input (Mini-jack) x 1
Audio output (Mini-jack) x 1
DC in Jack x 1
USB 3.2 Gen 1 Type-A x 4
LAN (RJ45) x 2
HDMI x 1
External VGA (15-pin; D-sub) x 1
Serial port (9-pin; D-sub) x 2 |
| |
______________________________ |
| Communication Interface |
10/100/1000 base-T Ethernet
Optional: Dedicated GPS |
| |
______________________________ |
| Pre-installed Software |
Getac Utility
Getac Geolocation
Adaptec Storage Manager™ ii
Optional: Absolute Persistence® |
| |
______________________________ |
| Security Features |
TPM 2.0
Kensington lock
Intel® vPro™ Technology
Smart card reader |
| |
______________________________ |
| Power |
AC adapter (150W, 100-240VAC, 50/60Hz)
Li-ion smart battery (10.8V, 9240mAh, 99.8Wh)
Optional: Multimedia bay 2nd Li-ion smart battery (10.8V, 9240mAh, 99.8Wh) ii |
| |
______________________________ |
| Dimension (W x D x H) & Weight |
410 x 320 x 65mm (16.1" x 12.6" x 2.5")
5.2kg (11.4lbs) iii
410 x 320 x 119mm (16.1" x 12.6" x 4.6") iv
8.6kg (18.9lbs) iii,iv |
| |
______________________________ |
| Rugged Features |
MIL-STD-810H certified
IP65 certified
Vibration & drop resistant
Full magnesium alloy case
Shock-protected removable HDD |
| |
______________________________ |
| Environmental Specifications |
Temperature v:
- Operating: -20°C to 55°C / -4°F to 131°F
- Storage: -40°C to 71°C / -40°F to 160°F
Humidity:
- 95% RH, non-condensing |
| |
______________________________ |
| Accessories |
Battery (10.8V, 9240mAh, 99.8Wh)
AC adapter (150W, 100-240VAC)
Optional:
Backpack ii
Battery (10.8V, 9240mAh, 99.8Wh)
Multimedia bay 2nd HDD ii
Multimedia bay 2nd battery (10.8V, 9240mAh, 99.8Wh) ii
Multi-Bay charger (Dual-Bay)
AC adapter (150W, 100-240VAC)
Office dock AC adapter (150W, 100-240VAC)
Protection film |
| |
______________________________ |
| Bumper-to-Bumper Warranty |
Accidents can take your equipment out of service when you least expect it, especially in a rugged environment, which can cause costly equipment downtime.
That is why Getac has introduced accidental damage as standard under our Bumper-to-Bumper warranty, to help minimize your enterprise IT costs.
Bumper-to-Bumper is your hassle-free guarantee. That means you can depend on us to have your unit back in service within days.
Standard
5 years Bumper-to-Bumper |
